Quiet heavy load linear guideway are precision transmission components designed specifically for high-load, low-noise environments. Combining heavy-duty capacity with quiet operation, they are widely used in noise-sensitive industrial applications requiring high loads.
Low noise design: less then 5 dB
Contact angle : 45°
Smoother movement: 2 times
Product Details
The development of QH series linear quideway is based on a four-row circular-arc contact. The QH series linear guidewaywith SynchMotion。 Technology ofers smooth movement, superior lubrication, quieter operation and longer runninglife.
Therefore the quiet heavy load linear guideway has broad industrial applicability. In the high-tech industry where high speedlow noise, and reduced dust generation is reguired, the QH series is interchangeable with the HG series.
Quiet Heavy Load Linear Guideway Features
1. Low Noise Design With SynchMotion” technology, rolling elements are interposed between the partitions of SynchMotion” to provideimpoved circulation. Due to the elimination of contact between the roling elements, noise levels due to collision aredrastically reduced.
2. Self-Lubricant Design
The partition is a grouping of hollow ring-like structures formed with a through-hole to facilitate circulation of thelubricant. Because of the special lubrication path design, the lubricant of the partition storage space can be refiledTherefore, the frequency of lubricant refilling can be decreased.
The QH-series linear guideway is pre-lubricated. Performance testing at a 0.20 (basic dynamic load) shows that afterrunning 4,000km no damage was apparent to either the rolling elements or the raceway.
Quiet Heavy Load Linear Guideway Application
Precision measurement equipment
Semiconductor equipment
Automation equipment
Laser Engraving machine
Can be widely used in high-tech industry requiring high speed,low noise,low dust generation
